Video reference: “7 line Zigzag stitching Machine embroidery” by M embroidery515
Turn ordinary zigzag into sculpted borders. This hands-on guide walks you through seven flowing, decorative stitch lines—S-scrolls, reversed S, hearts, intertwined S, block S, waves, and figure-eights—using a free-motion approach you can master with practice. Expect smooth curves, dense fills, and clean repeats, even on your first project.
What you’ll learn
- How to set up a standard sewing machine for free-motion zigzag borders (including feed handling and fabric control).
- A clear path for seven border motifs: S, reverse S, hearts, intertwined S (2×2 cm), block S (2×2 cm), waves, and figure-eights.
- How to vary zigzag width on the fly for sculpted lines.
- Practical checks to keep shapes consistent and spacing even.
- Fast fixes for gaps, distortions, and wobbly curves.
Unveiling the Art of Zigzag Machine Embroidery Zigzag is more than a utility stitch—guided free-hand, it becomes a drawing tool for borders. In this technique, you manually steer the fabric while the machine creates a zigzag that can be widened or narrowed smoothly. That control lets you outline, fill, and accent decorative shapes in one continuous pass.
Why borders? They frame hems, runners, cushion edges, and quilt bands with personality. Each pattern below uses a continuous path so your stitching flows steadily, producing dense, dimensional texture in alternating thread colors.
Essential Tools and Materials for Your Project
- Sewing machine capable of zigzag and free-motion work. The creator uses an industrial zigzag machine (Singer 20U) and controls width by knee pressure.
- Fabric: a flat swatch to practice borders.
- Threads: contrasting colors for clarity (purple, pink, orange are shown).
- Marking tools: pencil or marker for guides and 2×2 cm grids where noted.
- Needle suited to your fabric.
- Embroidery frame to keep fabric tight (the creator emphasizes tight fabric and comfortable thread tension for clean results). embroidery frame
Pro tip: If you prefer a tool that grips fabric evenly without hoop screws, many stitchers explore options like magnetic embroidery hoops to hold fabric taut while practicing dense fills.
Watch out: Over-tight top tension or a slack fabric sandwich can pucker dense areas and distort curves. The creator notes two essentials for clean stitches: thread not too tight and fabric stretched tight in the frame.
Prep checklist
- Fabric is pressed and framed tight.
- Thread chosen for high contrast.
- Design lines lightly sketched (and a 2×2 cm grid for the intertwined and block S patterns).
- Knee-width control or equivalent width control is reachable and responsive.
Setting Up Your Machine for Success
- Free-motion mode: Use a standard sewing machine adapted for free-motion embroidery (typically by dropping the feed dogs) so you—not the feed—direct the fabric path.
- Width control: On the Singer 20U used by the creator, zigzag width is controlled by knee pressure, enabling thick-to-thin modulation mid-stitch.
- Tension: The creator adjusted thread so it was not too tight, paired with taut fabric. This helps dense fills look smooth and prevents puckers.
- Framing: Keep the fabric stretched tight in an embroidery frame for consistent control.
Quick check: With the needle down, gently push the fabric side to side—stitch width should respond smoothly and predictably to your control.
Setup checklist
- Free-motion engaged; presser interactions aren’t dragging the fabric.
- Width control test yields smooth changes.
- Thread tension samples look balanced (no loops on the underside, no tunneling on top).
- Fabric framed drum-tight.
Step-by-Step Guide to 7 Unique Border Patterns Each motif follows the same rhythm: outline → fill → add accents where shown. Maintain a steady machine speed and adjust fabric speed for line weight and accuracy.
1) S-Scroll (purple) - Outline the first S gently, aiming for smooth, even curves.
- Fill the shape with a dense zigzag, moving back and forth to build a solid body.
- Add small circular dots along the lower edge for a dotted accent.
- Target result: a bold S with uniform density and neat dot accents.
Quick check: Curves should appear evenly rounded with no flat spots; dots should be similar in size and spacing.
Watch out: Uneven speed can cause wobble or thin spots. Slow your hands at the tightest curve to maintain density.
2) Reversed S-Scroll (pink) - Mirror your first S in the opposite direction; outline first.
- Fill densely, matching the character of the first line so both borders read as a pair.
- Add interior scroll details to enrich the flow; keep spacing even.
Pro tip: Before filling, pause with the needle down to realign your hand position—this avoids a visible jog where the fill begins.
3) Hearts (orange) - Trace a heart outline; then repeat hearts so each one interlocks cleanly with the next.
- Fill each heart with dense zigzag to form a continuous chain.
Quick check: Heart tops should match in height, and the point should center consistently along the border path.
If your hearts are crowding: Advance the fabric slightly more between repeats to maintain breathing room.
4) Intertwined S (2×2 cm, purple) - Mark a 2×2 cm grid; sketch intertwined S-shapes within.
- Stitch the outlines precisely, then fill to keep overlaps distinct.
Watch out: If shapes spill beyond the grid, reduce your hand movement amplitude and follow the sketched lines more closely.
5) Block S (2×2 cm, pink) - Using a square guide, outline the blocky S with crisp angle changes.
- Fill the geometric sections evenly so each repeat looks like a precise tile.
Pro tip: For sharp corners, briefly pause with needle down before pivoting the fabric; resume at the same speed to avoid thread bumps.
6) Waves (orange) - Flow a continuous wave; prioritize smooth arcs and consistent peak-to-trough spacing.
- Fill to create a band of motion without thinning at the crests.
Quick check: Wave thickness should read uniform across the length—no “pinched” spots at tight turns.
7) Figure-Eight (purple) - Form continuous loops with even intersections. Keep each loop size consistent end to end.
- Fill to create a dense chain of eights that reads as one elegant ribbon.
Target result: Seven distinct, richly filled borders that display smooth curves, crisp geometry, and consistent spacing.
Operation checklist
- Outline first, then fill without lifting unnecessarily.
- Maintain steady machine speed; use your hands to steer density.
- At overlaps or corners, pause needle-down to stabilize.
- Compare repeat size to the previous motif before you continue.
Tips for Flawless Free-Motion Embroidery Smooth width changes (thick to thin)
- On the machine used by the creator, knee pressure controls zigzag width; gentle pressure changes deliver smooth, sculpted lines.
- Practice transitions on scrap: draw an S and vary width at the widest curve, then taper across straights. This mimics the rhythm of the borders.
Pro tip: When your hands speed up, perceived stitch density thins. Counter by slightly increasing width (via knee pressure or your machine’s width control) during faster moves. machine embroidery hoops
Even density in fills
- Build fills with a steady side-to-side motion that slightly overlaps previous passes.
- If you see gaps, narrow your sweep or make a second pass to mesh the stitches.
Clean geometry
- For grid-based motifs, let the pencil grid be your ruler. The grid keeps 2×2 cm repeats aligned and prevents drift over a long border.
Fabric stability
- The creator underscores two keys for clean results: thread not too tight and fabric packed tight in a frame. If you see puckering, reframe and retest tension.
Quick check: On test swatches, your backside should show a neat zigzag with no loops or nests; the top should look full without tunneling.
Quality Checks At key milestones, look for these hallmarks of success:
- S and reversed S: Even radii, mirrored proportions, and matching density.
- Hearts: Consistent height and centered points; no overlaps where you don’t intend them.
- Intertwined S: Each overlap reads clearly—no muddy joins.
- Block S: Right angles look crisp with no rounded corners.
- Waves: Peaks and troughs repeat cleanly; thickness remains uniform.
- Figure-eights: Loop size remains constant; intersections are centered.
If any line drifts, compare against your previous repeat, correct immediately, and use your grid or sketch to reset scale.
Results & Handoff When finished, you’ll have seven distinct border bands in alternating colors—dense and textured, ready to edge projects or serve as stitch-library samples. Photograph or catalog each sample with notes on thread, width behavior, and any adjustments you made so you can reproduce your best settings later.
Pro tip: If you stitch borders often, organizing your fabric framing can speed repeatability. Stitchers who handle many pieces frequently explore dedicated hooping aids and hooping stations to keep fabric alignment predictable.
Troubleshooting & Recovery Symptoms and likely fixes
- Jagged curves
- Likely cause: Hand speed surges in tight bends.
- Fix: Slow your hands at the apex; widen zigzag slightly during the turn for coverage. embroidery magnetic hoops
- Puckering or tunneling
- Likely cause: Thread too tight or fabric not tensioned in frame.
- Fix: Loosen top thread slightly; reframe fabric drum-tight (the creator cites both adjustments as helpful).
- Gaps in dense fills
- Likely cause: Side-to-side sweep too wide; inconsistent overlap.
- Fix: Narrow your sweep; add a second pass to mesh stitches.
- Irregular repeat size
- Likely cause: No visual scale reference.
- Fix: Mark a light grid or tick marks; compare each repeat against the last before continuing.
Common questions, answered inline
- Can you do this without an industrial machine? Yes—a standard sewing machine adapted for free-motion can handle these motifs.
- How do you change thick/thin mid-stitch? On the machine shown, zigzag width is controlled by knee pressure; gentle modulation sculpts the line.
- Do I need a special bobbin case? The creator specifically mentions adjusting thread (not too tight) and using a tight embroidery frame; they did not cite a bobbin case change.
Quick tests
- Before starting your border, stitch a 5–10 cm sample of your motif on scrap with the same framing and thread. Confirm width modulation works and the backside is clean.
Creative Applications for Your New Skills
- Sample library: Keep each of the seven lines on a single swatch to reference spacing, width behavior, and fill strategies. brother sewing machine
- Edge treatments: Frame napkins, pillowcases, table runners, or quilt sashing.
- Mix and match: Combine a geometric (block S) with an organic (wave) for contrast.
From the comments
- “What machine is that?” The creator uses an industrial zigzag Singer 20U. They note this model is no longer in production and recommend searching online for the replacement.
- “Industrial only, or can I use a home machine?” You can adapt a standard sewing machine for free-motion work (drop feed and manage fabric movement). The creator’s key technique is width control during motion.
- “Thick to thin—how?” Width is varied by knee pressure on the machine, giving smooth transitions while you stitch.
- “Puckering—help!” The creator reports success after loosening thread tension slightly and stretching fabric tight in an embroidery frame.
Conclusion: Your Journey into Decorative Embroidery With a tight frame, comfortable thread tension, and confident width control, zigzag becomes a brush you can paint with. Master the seven borders here—S-scrolls, hearts, grid-guided S variations, waves, and elegant figure-eights—and you’ll have a repeatable method for turning any straight edge into a signature finish. magnetic hoops for brother
Quick check before you leave the machine
- Fabric still drum-tight; stitches lie flat.
- Repeats align and match the neighboring unit.
- Backside is clean; no loops or nests.
- Notes recorded for the thread and width behavior you liked most. brother magnetic hoop
Gear note for frequent framers If you produce multiple borders in batches, a consistent framing workflow can help. Some stitchers explore dedicated aids and frames to minimize refits between passes; for example, simple frame swaps or tools with magnetic clamping can speed setup. magnetic hoops hoopmaster
