Mastering Barudan’s Float Function: Step-by-Step Guide to Fast, Precise Stitch Navigation

What is the Barudan Float Function and Why You Need It

Float is a non-sewing movement mode that makes the pantograph travel through your design’s stitch path without engaging the needle. That means you can navigate—quietly and precisely—to a stitch location you need to inspect or fix. It’s especially helpful when you discover miss-stitches on a finished product and want to correct them without rehooping.

Understanding Stitch-by-Stitch Navigation When Float is active, each forward or backward increment moves the pantograph to the next or previous stitch position in your design data, rather than driving the needle through the fabric. This keeps your piece safe while you line up a repair. barudan embroidery machine hoops

The Perfect Tool for Fixing Embroidery Errors If you see gaps, loose loops, or a section that didn’t catch properly, floating lets you park the needle right above the problem area. Once you’re satisfied with placement, you can exit Float, switch back to normal Drive sewing, and make your correction.

Pro tip - Keep your eye on the stitch number display—this is your compass. For large designs, noting the target stitch number before you move can save time.

Getting Started: Activating Drive Mode

Before anything else, make sure your machine is in Drive mode. The Float function is only available in Drive mode. The video explicitly calls this out as a prerequisite.

A Crucial Prerequisite for Floating - Confirm the Drive icon is active on the main screen. If not, tap it to enable. With Drive mode on, all Float features become available.

Watch out

• Attempting to use Float outside Drive mode won’t work. If buttons seem unresponsive, check the mode first. barudan magnetic hoops

Precise Adjustments with 1 Stitch Float

Think of 1 Stitch Float as your micro-adjust knob. It moves the pantograph exactly one stitch position at a time.

Moving Forward and Backward One Stitch at a Time - Tap the left arrow icon next to the stitch count to move backward by one stitch.

- Tap the right arrow icon to move forward by one stitch.

Quick check

• As you tap, the on-screen stitch number changes by one and the pantograph steps accordingly. If the number isn’t changing, confirm you’re on the main screen and that Drive mode is active.

Why it matters

• 1 Stitch Float is perfect for fine alignment over a tiny problem area—especially when you intend to resew just a few stitches.

Mastering the Float Screen Interface

When you need more control—and better visibility—switch to the dedicated Float screen. Here you’ll get a magnified view of your stitch path and access to high-speed movement options.

How to Enter Float Mode

To open the Float screen, press the center of the stitch number area on the main screen. Avoid the left and right arrow icons; tap the middle to enter.

Once in Float mode, you’ll see a zoomed-in, detailed view of the design and a new set of icons along the bottom for advanced navigation.

Continuous floating without sewing

• With the machine in Float mode, pressing the start button moves the pantograph stitch by stitch—without driving the needle. This is ideal for scanning over an area to inspect alignment.

Exiting Float Mode to Resume Sewing

When you’re ready to sew, exit the Float screen by pressing the Drive icon (above “J”). That returns you to normal operation in Drive so you can stitch from the current position.

Pro tip

• Want to return to the main screen but stay in Float mode? Press the Float icon (above “I”). This gives you a larger overall screen while keeping Float active. barudan magnetic embroidery frame

Jumping Ahead: High-Speed Float by Stitch Count

For big jumps—say you need to go from stitch 200 to stitch 5,000—use High-Speed Float by stitch count. It’s an efficient way to navigate long designs without holding down arrows.

Using Incremental Buttons for Quick Jumps On the Float screen, the +/-1 and +/-1000 icons let you nudge the target stitch number up or down by small or large steps. This is handy when you know the rough neighborhood you’re aiming for.

Entering a Specific Stitch Number with the Keypad

• Press the keypad icon (above “F”) to bring up the numeric keypad.

• Type the exact stitch number you want to reach.

- Press the Enter icon (above “E” or below the keypad) to execute the float.

The pantograph will travel directly to that stitch location. Before you run the machine from here, exit Float by pressing the Drive icon above “J,” then press Start to sew.

Quick check

• After a high-speed float, confirm the displayed stitch number matches your target.

Watch out

• For safety, make sure nothing is in the way of the pantograph before pressing Enter to execute the move. The video reiterates this warning. barudan mighty hoops

Navigating by Color: High-Speed Float by Color Change

If your design is organized into multiple color blocks, you can float by color change instead of stitch number. This is great for jumping to the start of a color section to verify alignment or resume work.

Switching to the Color Change Float Screen

On the Float screen, press the Next icon (above “F”) to toggle between the stitch-count float and the color-change float interface.

The display will indicate the color change selection (e.g., F=C03), so you know which block you’re targeting.

Jumping Between Color Sections in Your Design

• Use the “C+” and “C-” icons to advance to the next or previous color block.

- Press the Enter icon (above “E”) to execute the move.

The pantograph will reposition to the first stitch of the selected color block, ready for inspection or to resume sewing after you exit Float.

Pro tip

• If you’ve noted which color block contained a miss-stitch, this method is faster than hunting by stitch number. mighty hoops for barudan

Important Safety Considerations

The video emphasizes one critical safety point: ensure the pantograph’s path is clear before executing a high-speed float. That means no hands, tools, scraps, or thread spools near the movement area.

Safety checklist

• Confirm Drive mode is active before accessing Float features.

• Visually sweep the pantograph’s route—clear any obstacles.

• Announce the move if others are nearby.

• Execute the float; then verify your position before resewing.

Watch out

• Even though the needle doesn’t engage during Float, the gantry moves briskly during high-speed jumps—keep your workspace tidy and your fingers safe. barudan magnetic embroidery hoop

From the comments: Your questions, answered

We reviewed recent viewer comments related to this feature. Here are the top takeaways:

• Network transfer to Pro 3: One viewer asked how to set up a network to transfer files to a Pro 3 instead of using a thumb drive. The video does not cover networking setup. For accurate guidance, consult your machine’s official documentation or contact the manufacturer’s support.

• Single-head pricing: Another viewer asked about the price of a single-head machine. Pricing is not discussed in the video. For current quotes, reach out to an authorized dealer.

• General appreciation: Multiple viewers thanked the channel and asked for more training content—clearly, tutorials like this Float guide are helping the community.

From the comments

• If there’s a feature you want covered next (for example, file management or networking setups), leave a suggestion and specify your model. barudan magnetic hoops

FAQ

What is the Float function on a Barudan embroidery machine? Float lets you move the pantograph through a design’s stitches—either one at a time or via high-speed jumps—without sewing. It’s used for inspection, positioning, and precise error correction.

Can I use Float in any mode? No. Float is only available in Drive mode. Enable Drive to access Float screens and controls.

How do I jump to a specific stitch to fix a mistake? Enter the Float screen, open the keypad, type the exact stitch number, and press Enter. The pantograph will move directly to that stitch.

Is high-speed float safe? Yes—if you follow the safety note from the video: make sure the pantograph’s path is clear before executing the move.

Quick check

• After any float, confirm on-screen that you’re at the intended stitch or color block before resewing. barudan embroidery machine hoops

Wrap-up and Next Steps

With Float, you can navigate a design without stitching—perfect for inspecting, aligning, and fixing small errors. Remember the three tiers of control:

• 1 Stitch Float for fine nudges

• High-Speed Float by stitch number for direct jumps

• High-Speed Float by color change for block-level navigation

Before you resew, always exit Float by pressing the Drive icon above “J,” then press Start to resume from your current position. Keep the workspace clear for safety, and you’ll correct errors quickly and confidently.

If you found this useful, watch the full video for the on-screen icon locations and timing cues—and keep an eye out for more tutorials on efficient navigation and error correction.

Pro tip

• For larger, multi-hoop projects, consider planning checkpoints in your production notes—record stitch numbers or color blocks where issues commonly occur. That way, Float becomes your fast-lane to every critical spot. mighty hoops for barudan
